Low Weight 3K Carbon Fiber Roll Wrapped Twill Tube ~ 3" ID x 72", Gloss Finish

Product Description

Low Weight 3K Carbon Fiber Roll Wrapped Twill Tube ~ 3" ID x 72", Gloss Finish

LIJIN roll-wrapped twill carbon fiber tubes are fabricated from a combination of unidirectional and woven twill prepreg material and cello wrapped for a gloss finish. The unidirectional layers are oriented to provide high bending stiffness and axial strength. The inner and outer layers provide a bias support in addition to an attractive appearance. This product is ideal for building lightweight frames and structures, tubular vessels, poles, column supports, and any other application where low weight and high stiffness are essential, yet appearance is also important.

Our twill round carbon fiber tube is roll-wrapped from unidirectional carbon fiber with a 3k twill carbon fiber fabric outer layer. They not only offer a beautiful surface but also excellent torsional characteristics, as well as crush strength, and are ideal for high torque applications. This round tubing is ideal for building lightweight frames and structures, tubular vessels, poles, column supports, and any other application where low weight and high stiffness are essential and appearance is also important.

Our roll-wrapped carbon tubes come in various diameters, lengths, and thicknesses, If you want to buy a large-diameter carbon fiber tube or any other specific carbon fibre tube, do not hesitate to contact us, we can custom carbon fiber tube for you.

How to make carbon fiber tubing?

Our carbon fiber round tube is rolled unidirectional carbon fiber fabric into a mandrel, and roll wrapped a 3k finish fabric exterior. Unidirectional carbon fiber is the structural backbone of all our tubes, the 3k fabric weave that gives carbon fiber tubes their traditional ”carbon fiber look” is only the outside layer and helps with durability. Usually, any wall thickness can be made by changing the number of layers or combining different prepreg thicknesses (usually 0.15mm- 0.25mm thick per layer), Our round tubes typically use layups designed for optimal performance in a wide range of conditions.

We use 100% pure carbon fiber materials making carbon fiber tubing in a wide variety of diameters and lengths. Common diameter includes 2mm, 3mm, 4mm, 5mm, 6mm, 8mm, 10mm carbon fiber tube, ... 40mm carbon fiber tube, our round tube standard length is 1000mm, If you need a carbon fibre tube with other lengths or diameters, or need colored carbon fiber tube, do not hesitate to contact us, we can cut and custom carbon fiber tubes to your specified.

How to work with us?

If you want to get our carbon fiber tube price, please include ID, OD, length, dimensional tolerances, quantity, structural requirements, surface finish, surface pattern, material (if you know), temperature requirements, processing technology, etc. According to these points, we can easily and quickly quote you the price.
